INROLED_70—Robust LED Tubular Light for Industry and Facilities

INROLED_70

The INROLED_70 is a versatile LED tube light for machines, systems, and building installations – wherever powerful, robust, and uniform lighting is required.

Available with a borosilicate glass protective tube (safety glass) or an opal polycarbonate tube version, it delivers high light output with a diameter of 70 mm. Thanks to its daisy-chain capability, the INROLED_70 enables uniform and cost-efficient illumination of large areas.

Depending on the application, it is available as a 24 V DC version – ideal for flexible use in industrial, building, and facility applications.

Your Benefits

Flicker-free, high-intensity LED industrial light with homogeneous white light free of UV and IR radiation
Available with 4 mm borosilicate glass or shatterproof polycarbonate tube – providing optimal protection and pleasant, glare-free illumination
Universally applicable – easy to convert, retrofit, and electrically daisy-chain
Maximum protection: IP67/IP69K – dustproof and resistant to high-pressure water
Certified to CE and UKCA
100% Made in Germany – durable manufacturing quality backed by a 5-year warranty

Application Areas

Machines and systems
track construction machines
building services
underground parking facilities
architecture

Technology

High-performance LED chips with daylight-white light (5700 K) – extremely bright and efficient
Wide 125° beam angle and high color rendering (Ra >85) ensure natural light quality
Glare reduction through microprismatic or opal diffuser – for homogeneous, glare-free illumination
Minimal heat generation, with residual heat dissipated via a ribbed aluminum base
Simple electrical installation via cable gland with internal Wago terminal
Flexible mounting using standard Ø70 brackets or optional mounting components

Service

OM INROLED_70 24V DC (3.28 MB, PDF)

	Article number	Power consumption	Lamp luminous flux	Data sheet
INROLED_70 DC ECO, borosilicate glass, 13,94 inches, 24V DC	115010-01	~6,5 W	1000 lm	Data sheet
INROLED_70 DC ECO, borosilicate glass, 20,20 inches, 24V DC	115110-01	~11 W	1670 lm	Data sheet
INROLED_70 DC ECO, borosilicate glass, 25,59 inches, 24V DC	115210-01	~13 W	2004 lm	Data sheet
INROLED_70 DC ECO, borosilicate glass, 36,26 inches, 24V DC	115310-01	~21 W	3340 lm	Data sheet
INROLED_70 DC ECO, borosilicate glass, 47,80 inches, 24V DC	115410-01	~28 W	4342 lm	Data sheet

add to request cart Download CAD

Product Accessories

TUBELED_70 / INROLED_70 luminaire holder ± 180° (1 pair)

Item No.: 210200-02

add to request cart Datasheet
