Item No.: 213200-02
LED System Luminaire with Signal Function
UNILED SL RGB-W
Universal, shadow-free, and capable of signaling
The UNILED SL RGB-W is the first system luminaire that, in addition to providing balanced lighting, also offers a signaling function by changing the light color or by blinking. During regular illumination, system workstations have a pleasant, motivating light atmosphere. The opal-white diffuser creates a homogeneous, glare- and shadow-free illumination while still producing strong light output. Changes in workstation status can be indicated by a color change (for example, to green or red light) or by interval blinking.
Your Advantages
- Homogeneous, low-shadow, glare-free illumination without UV or IR radiation
- Pleasant atmosphere with daylight white 5200–5700K and signaling function via various colors
- The white light offers excellent color rendering and contrast values
- Opal-white diffuser for glare-free illumination
- Signaling via changing the light color or interval blinking
- Integrated mounting lugs
Application Areas
- System workstations
- Optical inspection workstations
- Testing workstations
- Color and paint inspections
- Also usable in machines without coolant lubricants and chip bombardment
The Technology
- High-performance LED cluster with separate LED chips for white light and RGB
- Rugged aluminum housing with integrated mounting for horizontal installation
- Optionally pivotable with wall or swivel brackets
- Powerful illumination of system workstations and work areas with 5200–5700K daylight white
- Beam angle 100° and color rendering (Ra) >85 at daylight white
- Cover with opal-white diffuser
- Signaling by changing the light color – all colors of the RGB color space are selectable
- Heat is dissipated to the rear via the aluminum base body
- Protection class IP 50 and above-average service life
- Supply voltage 24V DC via standardized M12 connector
- CE and ETL listed test seals
- Manufactured in Germany
Versions
- Four different lengths: 295 mm (approx. 11.6 in), 545 mm (approx. 21.5 in), 1045 mm (approx. 41.1 in), 1545 mm (approx. 60.9 in)
- Various light intensities
- Opal-white diffuser
UNILED SL RGB-W
| Article number | White lamp luminous flux | Lamp luminous flux RED | Lamp luminous flux GREEN | Lamp luminous flux BLUE | Data sheet | ||
|---|---|---|---|---|---|---|---|
| UNILED SL RGB-W, 11,61 inches, 24V DC | 110994-11 | 1215 lm | 240 lm | 355 lm | 150 lm | Data sheet | |
| UNILED SL RGB-W, 21,46 inches, 24V DC | 110994-12 | 2430 lm | 480 lm | 710 lm | 300 lm | Data sheet | |
| UNILED SL RGB-W, 41,14 inches, 24V DC | 110994-13 | 4860 lm | 960 lm | 1420 lm | 600 lm | Data sheet | |
| UNILED SL RGB-W, 60,83 inches, 24V DC | 110994-14 | 7290 lm | 1440 lm | 2130 lm | 900 lm | Data sheet |
Product Accessories
UNILED SL Leuchtenhalter Gelenkwinkel (1 Paar)
